Butyl Coating Machine for Aluminum Spacer

1.This machine is used for spacer glue coating after bending

2.Gas - liquid conversion system offers stable working performance
  • Model: SFJ-03
  • Description



    1. Touch Screen interface, PLC control system, digital display to control glue exturde and stop time.

    2.Glue cylinder and glue nozzle both automatic heating function.

    3.Automatic display function when out of glue

    4.Width of glue nozzle automatic adjust function




    Model SFJ-03
    Voltage 380V/50HZ
    Power 3KW
    Squeeze Pressure 12-16Mpa
    Working Speed 0-50m/min
    Glue Cylinder Diameter φ195
    Air Pressure 0.6-0.8Mpa
    Glue nozzle adjust range 4-27mm
    Dimension 3000x740x340mm


    Detailed Pictures
